Bm7b5 — B half-diminished seventh chord
A diminished triad with a minor seventh added. Three minor thirds separated by a major third.
- 1 = B
- b3 = D
- b5 = F
- b7 = A
- Symbol
- Bm7b5
- Root
- B
- Quality
- Half-diminished seventh
- Family
- seventh
- Notes
- B D F A
- Degree formula
1 b3 b5 b7- Semitones from the root
0 3 6 10- Distinct pitch classes
- 4
- Interval structure
- Stacked from the root: 3 semitones, 3 semitones, 4 semitones
- Notation
- Written m7b5 or with a slashed circle. The chord on the seventh degree of a major key, and the ii chord in a minor ii-V-i.
- Key
- B · B major / G# minor key signature
Formula
The chord tones in order from the root, with the interval each one forms above it.
| Degree | Note | Semitones | Interval from the root |
|---|---|---|---|
| 1 | B | 0 | Perfect unison |
| b3 | D | 3 | Minor third |
| b5 | F | 6 | Tritone |
| b7 | A | 10 | Minor seventh |
Inversions
An inversion is the same set of notes with a different one in the bass. The last column gives the distance of each note above the bass note, in semitones.
| Inversion | Bass note | Degree in the bass | Notes above the bass | Semitones above the bass |
|---|---|---|---|---|
| root position | B | 1 | B – D – F – A | 0 3 6 10 |
| first inversion | D | b3 | D – F – A – B | 0 3 7 9 |
| second inversion | F | b5 | F – A – B – D | 0 4 6 9 |
| third inversion | A | b7 | A – B – D – F | 0 2 5 8 |
Playable voicings
These shapes were found by searching the fretboard of a standard-tuned guitar (E A D G B E) rather than copied from a chord book. The search allows every string to sound or to be muted, rejects any shape with a muted string between two sounding strings, rejects any shape whose fretted notes span more than four frets (a five-fret window), requires every chord tone to be present, and then sorts what remains with root-position shapes first and the most compact, lowest shapes next. The shapes shown are the first six of that ordering; other orderings are possible at the same frets.
| # | Shape (low string first) | Notes | Degrees | Bass | Span (frets) | Sounding strings |
|---|---|---|---|---|---|---|
| 1 | 7-5-7-7-6-5 | B D A D F A | 1 b3 b7 b3 b5 b7 | B | 2 | 6 |
| 2 | 7-5-7-7-6-7 | B D A D F B | 1 b3 b7 b3 b5 1 | B | 2 | 6 |
| 3 | 7-8-7-7-6-7 | B F A D F B | 1 b5 b7 b3 b5 1 | B | 2 | 6 |
| 4 | 7-5-7-4-6-5 | B D A B F A | 1 b3 b7 1 b5 b7 | B | 3 | 6 |
| 5 | 7-5-7-4-6-7 | B D A B F B | 1 b3 b7 1 b5 1 | B | 3 | 6 |
| 6 | 7-8-7-7-6-5 | B F A D F A | 1 b5 b7 b3 b5 b7 | B | 3 | 6 |
Shape numbers run from the lowest string to the highest, so the left-hand number is the sixth string (low E) in standard tuning. Multiple shapes are listed because a chord can be voiced several ways, and because a lower position is not always the better sounding one.
